Direct vs Indirect Heating in Cylindrical Tanks:
Choosing the Right Approach for Your Process
|
| By PMJ Heaters Manufacturing Sdn Bhd
|
| Industrial Electric Heater & Thermocouple Manufacturer in Malaysia
|
|
|
|
|
|
.png "Understanding the Challenge: Heating a Cylindrical Tank Efficiently")
|
|
|
| Understanding the Challenge:
|
| Heating a Cylindrical Tank Efficiently
|
|
| In industries such as chemical processing, food manufacturing, and gas treatment, heating a cylindrical tank is a key operation. Yet, every medium — whether it’s water, oil, corrosive liquid, or even process gas — behaves differently when exposed to heat. Choosing between direct and indirect heating methods is crucial to balance efficiency, safety, and equipment longevity. At PMJ Heaters Manufacturing Sdn Bhd, our engineering team designs tailored heating systems to suit various tank configurations, materials, and process media.
|
|
|
|
|
|
|
.png "Direct Heating:Fast and Energy-Efficient")
|
|
|
| Direct Heating:
|
| Fast and Energy-Efficient
|
|
|
| Direct heating means the heating element is in physical contact with the process medium. This method offers maximum energy efficiency and faster temperature rise, with minimal heat loss.
|
|
|
| Common Direct Heating Solutions
|
- Immersion Heaters – Submerged directly into the liquid or gas flow.
- Flanged / Screw Plug Heaters – Installed through the tank wall for easy access.
- Circulation Heaters (Inline Units) – Heat moving liquids or gases in a closed loop
|
|
|
| When to Use Direct Heating
|
|
|
| Medium
|
Why It Works
|
Recommended PMJ Product
|
| Water
|
Non-corrosive and easy to circulate
|
PMJ Immersion Heater
|
| Low-viscosity oils
|
Good convection and heat transfer
|
PMJ Flanged Heater
|
| Clean process gases
|
Uniform and controlled heating inside tank or pipeline
|
PMJ Circulation Heater
|
|
|
|
|
| Considerations
|
| Direct heating is not ideal for corrosive liquids or materials prone to scaling, which can shorten heater life. In such cases, indirect heating is preferred.
|
|
|
|
|
|
|
|
.png "Indirect Heating: Safer for Corrosive or Sensitive Media")
|
|
|
| Indirect Heating:
|
| Safer for Corrosive or Sensitive Media
|
|
|
| In indirect heating, the heating element never touches the process medium. Instead, heat transfers through a protective barrier or tank wall, ensuring the heater stays isolated from corrosive or hazardous substances.
|
|
|
| Common Indirect Heating Methods
|
|
|
| a. Quartz or Protection Tube Heaters
|
The heater is inserted into a quartz, titanium, or stainless tube that sits inside the tank — ideal for acids, plating baths, and alkaline solutions.
Recommendation: PMJ Quartz Immersion Heater
|
|
|
| b. Quartz or Protection Tube Heaters
|
| Mounted outside the tank, transferring heat by conduction. The heater type depends on temperature and tank design:
|
- Mica Band Heater – up to 300 °C for mild steel or stainless tanks
- Tubular Band Heater – for uneven or large diameters
- Ceramic Band Heater – up to 600 °C for higher process temperatures
- Silicone Rubber Heater – flexible and ideal for FRP or plastic tanks
|
|
| Recommendation: PMJ Ceramic Band Heater | PMJ Silicone Rubber Heater
|
|
|
| c. Jacket Heating Systems
|
For high-capacity or temperature-critical tanks, a fluid jacket is used. A PMJ Inline Circulation Heater preheats oil or water, which circulates through the jacket coil and transfers heat evenly to the tank contents.
Recommendation: PMJ Quartz Immersion Heater
|
|
|
|
| When to Use Direct Heating
|
|
|
| Medium
|
Why It Works
|
Recommended PMJ Product
|
| Corrosive acids & chemicals
|
Isolates heater from fluid
|
Quartz Immersion Heater
|
| Adhesives or viscous oils
|
Gentle, uniform surface heating
|
Ceramic Band Heater
|
| FRP / plastic tanks
|
Prevents overheating or deformation
|
Silicone Rubber Heater
|
| Jacketed systems
|
Precise control with circulation
|
Inline Circulation Heater
|
|
|
|
|
| Advantages of Indirect Heating
|
- No contamination of the process medium
- Safer for corrosive, flammable, or high-purity materials
- Longer heater lifespan
- Compatible with round or irregular tank designs
- Adaptable for both liquid and gas heating applications within closed tanks or vessels
|
|
|
|
|
|
.png "Case Study: Upgrading a Chemical Process Tank")
|
|
|
| Case Study:
|
| Upgrading a Chemical Process Tank
|
|
|
| A chemical plant in Johor Bahru was facing frequent heater corrosion in its 1,000-litre acid neutralization tank. Their stainless steel immersion heaters failed every few months due to direct exposure.
|
|
|
| PMJ’s Solution:
|
| We designed a custom quartz-sleeved immersion heater, isolating the element from the liquid.
|
|
|
| Results:
|
- Heater lifespan increased from 3 months to over 24 months
- 12 % energy savings through optimized watt density
- Annual maintenance cost reduced by RM 15,000
|
|
|
| The project proved that with the right heating approach, performance and reliability improve together.
|
|
|
|
|
|
|
|
.png "PMJ Heaters – Engineered for Every Medium")
|
|
|
| PMJ Heaters
|
| – Engineered for Every Medium
|
|
|
| At PMJ Heaters Manufacturing Sdn Bhd, our solutions cover everything from direct immersion to indirect surface heating, designed for liquids, semi-solids, and even gas systems within tanks or circulation pipelines.
|
|
|
| Our product range includes:
|
- Immersion & Flanged Heaters
- Screw Plug Heaters
- Tubular & Finned Heaters
- Quartz & PTFE Heaters
- Band & Silicone Rubber Heaters
- Thermocouples & Sensors
- Custom Heating Assemblies
|
|
|
|
| All PMJ heaters are built under ISO 9001:2015 standards, tested for insulation resistance and temperature uniformity to ensure consistent industrial performance.
|
|
|
|
|
|
|
.png "Conclusion: The Right Heating Strategy Defines the Outcome")
|
|
|
| Conclusion:
|
| The Right Heating Strategy Defines the Outcome
|
|
|
| Whether your process involves heating water, oil, corrosive chemicals, or even process gases, the correct combination of heater type and heating approach ensures stable temperature control and long-term reliability.
|
|
|
| At PMJ Heaters, we don’t just supply products — we engineer solutions that keep your process efficient, safe, and consistent
|
|
|
| Contact our engineering team today for expert advice on your next heating project.
|
|
|
|
|
|
